VBT Series Wire Basket Tray System
The VBT Series Wire Basket Tray System is a configurable wire mesh basket system specially designed for the routing and proper protection of most cabling. This system is offered in 2” Depth, 4” Depth, and 6” Depth in multiple width options to suit your specific installation requirements and includes a wide variety of optional accessories for mounting and connecting basket sections.
For more information on how various components of the system work together to easily route and protect cabling, please download our Wire Basket Tray System Guide, and our Wire Basket Tray Installation Guide.
Basket Tray
Center Clip
Radius Splice
Corner Splice Kit
Washer Splice Kit
Cable Drop 3.5”W
Wire Basket Tray System Options
| Item Number | Description | Finish | Spec Sheet | Tech Drawing | ||
|---|---|---|---|---|---|---|
| VBT-ST05050-BP | 2”D x 2”W x 10’L Wire Basket Tray [Special Order] | Black Powder Coat |  |
|||
| VBT-ST05100-BP | 2”D x 4”W x 10’L Wire Basket Tray [Special Order] | Black Powder Coat | |
|
||
| VBT-ST05100-EG | 2”D x 4”W x 10’L Wire Basket Tray | Electrogalvanized Zinc | |
|
||
| VBT-ST05150-BP | 2”D x 6”W x 10’L Wire Basket Tray [Special Order] | Black Powder Coat | |
|||
| VBT-ST05200-BP | 2”D x 8”W x 10’L Wire Basket Tray [Special Order] | Black Powder Coat | |
|||
| VBT-ST05300-BP | 2”D x 12”W x 10’L Wire Basket Tray | Black Powder Coat | |
|
||
| VBT-ST05300-EG | 2”D x 12”W x 10’L Wire Basket Tray | Electrogalvanized Zinc | |
|
||
| VBT-ST05400-BP | 2”D x 16”W x 10’L Wire Basket Tray [Special Order] | Black Powder Coat | |
|||
| VBT-ST05450-BP | 2”D x 18”W x 10’L Wire Basket Tray | Black Powder Coat | |
|
||
| VBT-ST05500-BP | 2”D x 20”W x 10’L Wire Basket Tray [Special Order] | Black Powder Coat | |
|||
| VBT-ST05500-EG | 2”D x 20”W x 10’L Wire Basket Tray [Special Order] | Electrogalvanized Zinc | |
|||
| VBT-ST05600-BP | 2”D x 24”W x 10’L Wire Basket Tray [Special Order] | Black Powder Coat | |
|||
| VBT-ST10100-BP | 4”D x 4”W x 10’L Wire Basket Tray [Special Order] | Black Powder Coat | |
|||
| VBT-ST10150-BP | 4”D x 6”W x 10’L Wire Basket Tray [Special Order] | Black Powder Coat | |
|||
| VBT-ST10200-BP | 4”D x 8”W x 10’L Wire Basket Tray [Special Order] | Black Powder Coat | |
|||
| VBT-ST10300-BP | 4”D x 12”W x 10’L Wire Basket Tray | Black Powder Coat | |
|
||
| VBT-ST10400-BP | 4”D x 16”W x 10’L Wire Basket Tray | Black Powder Coat | |
|||
| VBT-ST10450-BP | 4”D x 18”W x 10’L Wire Basket Tray | Black Powder Coat | |
|
||
| VBT-ST10500-BP | 4”D x 20”W x 10’L Wire Basket Tray [Special Order] | Black Powder Coat | |
|||
| VBT-ST10600-BP | 4”D x 24”W x 10’L Wire Basket Tray [Special Order] | Black Powder Coat | |
|||
| VBT-ST15300-BP | 6”D x 12”W x 10’L Wire Basket Tray [Special Order] | Black Powder Coat | |
|||
| VBT-ST15400-BP | 6”D x 16”W x 10’L Wire Basket Tray [Special Order] | Black Powder Coat | |
|||
| VBT-ST15500-BP | 6”D x 20”W x 10’L Wire Basket Tray [Special Order] | Black Powder Coat | |
|||
| VBT-ST15600-BP | 6”D x 24”W x 10’L Wire Basket Tray [Special Order] | Black Powder Coat | |
| Item Number | Description | Finish | Spec Sheet | Tech Drawing | |
|---|---|---|---|---|---|
| VBT-SW-BP-B50 | Washer Splice Kit (Bag of 50) | Black Powder Coat | |
|
|
| VBT-SW-EG-B50 | Washer Splice Kit (Bag of 50) | Electrogalvanized Zinc | |
|
|
| VBT-SA-BP-B50 | Snap-in Splice Kit (Bag of 50) | Black Powder Coat | |
|
|
| VBT-SQ-BP-B50 | Quick Splice Bar (Bag of 50) | Black Powder Coat | |
|
|
| VBT-SB-BP-B10 | Bar Splice Kit | Black Powder Coat | |
|
|
| VBT-SC-BP | Corner Splice Kit | Black Powder Coat | |
|
|
| VBT-SR05140-BP | Radius Splice for 2"D Tray | Black Powder Coat | |
|
|
| VBT-SR10140-BP | Radius Splice for 4"D Tray | Black Powder Coat | |
|
|
| VBT-SR10140-EG | Radius Splice for 4"D Tray | Electrogalvanized Zinc | |
|
|
| VBT-SR15140-BP | Radius Splice for 6"D Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-CC-BP-B50 | Center Clip (Bag of 50) | Black Powder Coat | |
|
|
| VBT-CC-EG-B50 | Center Clip (Bag of 50) | Electrogalvanized Zinc | |
|
|
| VBT-CD45-BP | Cable Drop 1.75”W for Basket Tray | Black Powder Coat | |
|
|
| VBT-CD90-BP | Cable Drop 3.5”W for Basket Tray | Black Powder Coat | |
|
|
| VBT-CD90-EG | Cable Drop 3.5”W for Basket Tray | Electrogalvanized Zinc | |
|
| Item Number | Description | Finish | Spec Sheet | Tech Drawing | |
|---|---|---|---|---|---|
| VBT-WL100-BP | L Bracket for 4”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-WL150-BP | L Bracket for 6”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-WL200-BP | L Bracket for 8”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-WL300-BP | L Bracket for 12”W Basket Tray | Black Powder Coat | |
|
|
| VBT-WL400-BP | L Bracket for 16”W Basket Tray | Black Powder Coat | |
|
|
| VBT-WM100-BP | M-type L Bracket for 4”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-WM150-BP | M-type L Bracket for 6”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-WM200-BP | M-type L Bracket for 8”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-WM300-BP | M-type L Bracket for 12”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-WM400-BP | M-type L Bracket for 16”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-WS100-BP | Shelf Bracket for 4"W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-WS150-BP | Shelf Bracket for 6"W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-WS200-BP | Shelf Bracket for 8"W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-WS300-BP | Shelf Bracket for 12"W Basket Tray | Black Powder Coat | |
|
|
| VBT-WS400-BP | Shelf Bracket for 16"W Basket Tray | Black Powder Coat | |
|
|
| VBT-WS450-BP | Shelf Bracket for 18"W Basket Tray | Black Powder Coat | |
|
|
| VBT-WZ-BP | Wall Mount Bracket for 2” and 4” Width Basket Tray | Black Powder Coat | |
|
|
| VBT-WC-BP | Wall Clip for 2” and 4” Basket Tray | Black Powder Coat | |
| Item Number | Description | Finish | Spec Sheet | Tech Drawing | |
|---|---|---|---|---|---|
| VBT-BU100-BP | Cross Bar for 4”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-BU200-BP | Cross Bar for 8”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-BU300-BP | Cross Bar for 12”W Basket Tray | Black Powder Coat | |
|
|
| VBT-BU300-EG | Cross Bar for 12”W Basket Tray | Electrogalvanized Zinc | |
|
|
| VBT-BU400-BP | Cross Bar for 16”W Basket Tray | Black Powder Coat | |
|
|
| VBT-BU450-BP | Cross Bar for 18”W Basket Tray | Black Powder Coat | |
|
|
| VBT-BU500-BP | Cross Bar for 20”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-BU600-BP | Cross Bar for 24”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-BM100-BP | M-Type Cross Bar for 4”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-BM200-BP | M-Type Cross Bar for 8”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-BM300-BP | M-Type Cross Bar for 12”W Basket Tray | Black Powder Coat | |
|
|
| VBT-BM400-BP | M-Type Cross Bar for 16”W Basket Tray | Black Powder Coat | |
|
|
| VBT-BM450-BP | M-Type Cross Bar for 18”W Basket Tray | Black Powder Coat | |
|
|
| VBT-BM500-BP | M-Type Cross Bar for 20”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-BM600-BP | M-Type Cross Bar for 24”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-HB-BP | Hanging Bracket for 2”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-HC-BP | Hanging Clip for up to 12”W Basket Tray | Black Powder Coat | |
|
| Item Number | Description | Finish | Spec Sheet | Tech Drawing | |
|---|---|---|---|---|---|
| VBT-FB050-BP | Floor Mount Bracket for 2”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-FB100-BP | Floor Mount Bracket for 4”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-FB150-BP | Floor Mount Bracket for 6”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-FB200-BP | Floor Mount Bracket for 8”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-SO05100-BP | 2” Stand-Off Kit for 4”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-SO10100-BP | 4” Stand-Off Kit for 4”W Basket Tray | Black Powder Coat | |
|
|
| VBT-SO10200-BP | 4” Stand-Off Kit for 8”W Basket Tray | Black Powder Coat | |
|
|
| VBT-SO20300-BP | 8” Stand-Off Kit for 12”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-SO20400-BP | 8” Stand-Off Kit for 16”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-SO20450-BP | 8” Stand-Off Kit for 18”W Basket Tray | Black Powder Coat | |
|
|
| VBT-SO20500-BP | 8” Stand-Off Kit for 20”W Basket Tray [Special Order] | Black Powder Coat | |
|
|
| VBT-SO20600-BP | 8” Stand-Off Kit for 24”W Basket Tray [Special Order] | Black Powder Coat | |
|
Click on the item SKUs for additional information about specific products or contact your Vericom representative.
